TUGAS PERTEMUAN 5 ADM JARINGAN
CONFIGURING RAPID PVST+ Tabel IP Device Interface IP Address Subnet Mask Default Gateway S1 VLAN 99 172.17.99.11 255.255.255.0 N/A S2 VLAN 99 172.17.99.12 255.255.255.0 N/A S3 VLAN 99 172.17.99.13 255.255.255.0 N/A PC1 NIC 172.17.10.21 255.255.255.0 172.17.10.254 PC2 NIC 172.17.20.22 255.255.255.0 172.17.20.254 PC3 NIC 172.17.30.23 255.255.255.0 172.17.30.254 Spesifikasi Vlan pada Switch Port Ports Assignments Network S2 F0/6 VLAN 30 172.17.30.0/24 S2 F0/18 VLAN 20 172.17.20.0/24 S2 F0/11 VLAN 10 172.17.10.0/24 Langkah : 1. Konfigurasi PC PC 1 PC 2 PC 3 2. konfigurasi VLAN Switch 1 Swicth 2 Switch 3 3. Verifikasi VLAN Switch 1 Switch 2 Switch 3 4. Tentukan Trunk ke VLAN 99 lakukan di Switch1 : S1(config)# interface range f0/1-4 S1(config-if-range)# switchport mode trunk S1(config-if-range)# switchport trunk native vlan 99 lakukan di Switch2 : S2(config)# interface range f0/1-4 S2(config-if-range)# switchport mode trunk S2(config-if-range)# switchport trunk native
